JWrada-34 radar level meter gives reliable level measurement in applications that need long range and stable output. It works with liquids, powders, and solid materials. It also suits both tanks and silos. Because it uses non-contact radar measurement, it reduces wear, contamination, and maintenance during long-term use.
This model uses 80 GHz millimeter-wave FMCW radar technology and a 58 mm antenna lens. It measures up to 120 meters. Therefore, it fits large vessels, storage silos, and process tanks where long-distance measurement is important.
80 GHz Radar Level Meter for Steam, Foam, and Dust
The instrument handles difficult process conditions well. It performs reliably in steam, foam, dust, vapor, and agitation. Its intelligent echo-learning algorithm filters false echoes, separates multiple echoes, and tracks the real target signal. As a result, the device keeps stable measurement even when process conditions change.
The device also supports HART communication and built-in Bluetooth 5.0. Users can complete local wireless setup and monitoring through the Jiwei Smart Control mini-program. It also supports cloud-based remote access. This helps reduce field work and improves maintenance efficiency.
Explosion-Proof Radar Level Meter for Harsh Industrial Environments
This radar level meter is built for hazardous industrial environments. It supports gas and dust explosion-proof requirements. For this reason, it suits plants and process sites that need safe and reliable operation. The device also works in applications with process temperatures up to 220ยฐC. That makes it a strong choice for demanding thermal processes.
Its robust design also works in corrosive media applications when users choose suitable materials and sealing structures. Therefore, it suits industries that need long-range measurement and strong resistance to harsh conditions.
Typical Applications
JWrada-34 radar level meter is widely used in steam-filled vessels, foamy liquid applications, powder storage systems, solid granule handling, hot oil tanks, boilers, high-temperature process vessels, and corrosive industrial tanks. It is especially useful in chemical plants, petrochemical systems, and utility installations that need accurate long-range measurement.
For other radar solutions, see the [JWrada-32 Radar Level Meter] and the [JWrada-35 Radar Level Meter]. The device also supports [HART communication] for easier integration into industrial control systems.
