JWrada-31 Radar Level Meter for Liquid Measurement
The JWrada-31 radar level meter is a reliable solution for liquid level measurement in industries that need clean operation, stable performance, and accurate results. It is designed for non-explosion-proof areas and works well in tanks, vessels, and process systems where non-contact measurement is preferred.
This model uses 80 GHz Frequency Modulated Continuous Wave technology and an integrated antenna design with a 36 mm lens antenna. It supports a measuring range of up to 60 meters. As a result, it can deliver precise level monitoring in both small and large industrial tanks. Because the instrument does not touch the medium, it helps reduce wear, corrosion, and contamination during long-term use.
Smart Operation and Stable Signal Performance
The device comes with HART communication and built-in Bluetooth 5.0. Therefore, users can complete local setup and wireless monitoring through the Jiwei Smart Control mini-program. It also supports cloud-based remote monitoring, which helps operators manage instrument status more efficiently.
In addition, the JWrada-31 radar level meter uses intelligent echo processing to improve signal quality. It can suppress false echoes, separate multiple echoes, and track the true target signal in changing process conditions. Because of this, the instrument keeps stable performance even in applications affected by steam, dust, agitation, temperature variation, or pressure changes.
Low-Maintenance Design for Industrial Use
The JWrada-31 radar level meter uses a non-contact measuring principle, so it avoids many common problems found in contact-type instruments. It does not suffer from probe wear, and it helps reduce maintenance work in demanding industrial environments. Its compact design also makes installation easier in many common tank and vessel applications.
The instrument is suitable for pharmaceutical mixing tanks, food processing vessels, condensate tanks, lube oil tanks, dosing tanks, sedimentation tanks, and other liquid level applications. It is especially useful where stable measurement, easy operation, and long service life are important.
